HMF961 Mobile pneumatic lifting light
發布時間: 2019-08-10 15:26
HMF961 Mobile pneumatic lifting light
MAIN STRUCTURE |
? The lamps, pneumatic telescopic mast, and generator set are all included in the overall structure. Additionally, there are two universal wheels and two directional wheels at the bottom of the generator set, making it easy to move.
? Lighting system：Consists of 4 high-brightness lamps with a long service life and good waterproof performance. The lamp cap can adjust the projection angle in both vertical and horizontal directions.
? Lifting system：The pneumatic lifting mast can reach a height of 3-6 meters. Use an air pump or manual air valve to control the lifting rod of the expansion rod.
? Power system：gasoline generator set or diesel generator set can be selected.
? Control system：Each lamp and mast can be easily controlled via a stepless remote controller with a range of 50 meters. Additionally, we offer manual control switches for added convenience.
Support customization | Model code | |||
1 | 3 | 5 | 6 | |
HMF961-G | HMF961-D- | HMF961-G- | HMF961-D- | |
-3KW-4×500W | 3KW-4×500W | 5KW-4×1000W | 5KW-4×1000W | |
Lighting system | ||||
Voltage/Frequency | AC220V 50Hz | AC220V 50Hz | AC220V 50Hz | AC220V 50Hz |
Light Source | Halogen Lamp | Halogen Lamp | Halogen Lamp | Halogen Lamp |
Power of lights | 4×500W | 4×500W | 4×1000W | 4×1000W |
Luminous flux | 9500Lm | 9500Lm | 18000Lm | 4×18000Lm |
operatint hours with all lights on | 13h | 13h | 13h | 13h |
Irradiation distance | 30～100meters | 30～100meters | 30～100meters | 30～100meters |
protection grade | IP65 | IP65 | IP65 | IP65 |
Lamp control manner | Wireless remote control and manual switch | |||
Lifting system | ||||
Mast type | Pneumatic lifting | Pneumatic lifting | Pneumatic lifting | Pneumatic lifting |
Max height | 3.5meters | 3.5meters | 3.5meters | 3.5meters |
Mast Material | Aluminium | Aluminium | Aluminium | Aluminium |
Mast size | Φ70×1600mm | Φ70×1600mm | Φ70×1600mm | Φ70×1600mm |
Mast weight | 8kg | 8kg | 8kg | 8kg |
Mast Packaging size | 1610×110×125mm | 1610×110×125mm | 1610×110×125mm | 1610×110×125mm |
Mast control manner | Wireless remote control and manual switch | |||
Power system | ||||
Generator type | Gasoline | Diesel | Gasoline | Diesel |
Rated voltage | AC220V 50HZ | AC220V 50HZ | AC220V 50HZ | AC220V 50HZ |
Power | 3KW | 3KW | 5KW | 5KW |
Fuel tank capacity | 10L | 12.5L | 12.5L | 16L |
Oil capacity | 0.6L | 1.1L | 1.1L | 1.65L |
Start Method | Manual | Electric | Electric | Electric |
Weight & Size | ||||
Weight | 80kg | 110kg | 140kg | 150kg |
Size | 750×500×4500mm | 820×550×4500mm | 820×550×6000mm | 820×550×6000mm |
Packaging size | 800×535×700mm | 980×580×800mm | 980×580×800mm | 980×580×800mm |
Packaging | ||||
Packaging Details | Corrugating carton box or wooden case | |||
